REEFER, BUILT IN 1990, DWT 4600

NUMBER

REF173

TYPE

REEFER

FLAG

NETHERLANDS

BUILT YEAR

1990-12

BUILT PLACE

JULIANA GIJONESA GIJON, SPAIN

CLASS

GL  ICE STR POSS

SS

2015-07

DD

2015-07

LOA

105.35 M

LBP

BEAM

16.0 M

DEPTH

9.6 M

DRAFT

6.81 M (TROPICAL)

6.90 M (SUMMER)

6.81 M(WINTER)

GT

4190 MT ((INTERNATIONAL)

NT

2006 MT (INTERNATIONAL)

2977.79 MT (PANAMA)

3917.49 MT (SUEZ)

DWT

4467 MT (TROPICAL)

4600 MT(SUMMER)

4467 MT(WINTER)

FLOOR SPACE CAPACITY

2213.22 SQM

GEAR

CRANE, 3 x 5.0MT

ALLOWABLE WEIGHT OF FORKLIFT

MAXIMUM 5 MT (FORLIFT TO BE EQUIPED WITH MINIMUM 4 AIRTYRES)

ME

B&W 6L35MC, 4560 HP, 200 RPM

AE/GENERATOR

SPEED/CONSUMPTION

14.5 KTS ON 13(380)+1; 2.5(380)+0.2; 1.5MDO

FUEL TYPE

IFO 380

MDO

HOLD NUMBER

4

HATCH NUMBER

4

HATCH SIZE

COMPARTMENT

11

ZONES

8

TANK CAPACITY

490MT IFO 380

95MT MDO

DECKS

3

DECK AREA

DECK HEIGHT

MIN 2.20M

CAPACITY (CBFT)

199618

CAPACITY (CBM)

5589

BUNKER TANK CAPACITY

IFO 380 (RMG 380) 524CBM (490MT)

MDO (DMB)121CBM (95MT)

TYPE OF THE VENT SYSTEM

VENT

VERT

TEMPERATURE

-25+12 DC

TEMPERATURE ZONES

8

INDEPENDENT COOLING SECTIONS

1A/B, 2A/BC, 3A/BC, 4A/BC

AIR CHANGE

80/HR

AIR RENEWAL

3/HR

CONTAINER

6 FEU ON DECK

INSPECTION PLACE

SPAIN / INDIAN OCEAN

PRICE

USD 3.5 MILLION

REMARKS

1650 PALLETS

6 FEU ON DECK

8 REEFER PLUGS
