REF489/REEFER/1993-11-15/12137CBM/ USD 7.5 MILLION

NAME

REF489

TYPE

REEFER

FLAG

LIBERIA

PORT OF REGISTRY

MONROVIA

BUILT YEAR

1993-11-15

BUILT PLACE

FUKUOKA S.B, JAPAN

CLASS

RMRS KM ICE1

SS

2018-09

DD

2015-08

LOA

135.50M

LBP

127.96M

BEAM

20.20M

DEPTH

10.50M

DRAFT

7.750 M

GT

7533MT

8467MT (PANAMA)

8265MT (SUEZ)

NT

5330MT

6846MT (PANAMA)

6777MT (SUEZ)

DWT

8383MT (SUMMER)

8052MT (WINTER)

LDT/ DRAFT

4274 MT / 3.149M

FLOOR SPACE CAPACITY

4613 SQM

49654 SQFT

DOORS

SIDEDOORS 4P  2 x 2M x3, 1.5 x 1.3M

GEAR

DERRICKS 8X5T SWL OR 4X3.5T SWL UP

ALLOWABLE WEIGHT OF FORKLIFT

MAXIMUM 5 MT (FORLIFT TO BE EQUIPED WITH MINIMUM 4 AIRTYRES)

ME

AKASAKA-MITSUBISHI 8UEC45LA 9600 BHP (7060KW) x 158 RPM

AE/GENERATOR

3 x 480KW 3XDAIHATSU 6DL-20 750PS x 3

SPEED/CONSUMPTION

18.5 KONTS ON 27.5 (380)+1.5-4 (380)

FUEL TYPE

IFO 380

BUNKERS (IFO 380)

1077 MT IFO 380 RMG 35

BUNKERS (MDO)

89 MT IFO 380 RMG 35

HOLD NUMBER

4

HATCH NUMBER

4

HATCH SIZE

COMPARTMENT

15

DECKS

4

DECK AREA

DECK HEIGHT

≥2.20

WATER CAPACITY

FRESH WATER - 171.8MT

DRINKING WATER - 74.1MT

BALLAST WATER - 507.25 MT

CAPACITY (CBFT)

428618

CAPACITY (CBM)

12137

TEMPERATURE ZONES

8

TYPE OF THE VENT SYSTEM

VENT

VERT

TEMPERATURE

-30/+15

INDEPENDENT COOLING SECTION

1 A/BC, 2 AB/CD, 3 AB/CD, 4 AB/CD

AIR CIRCULATIONS

90/Hr

AIR RENEWALS

4/Hr

USDA

YES,  VALID UNTIL 01/01/2014

360 QUALITY CERTIFICATE

VALID UNTIL 15/09/2011

ANCHORS/ ANCHORS CHAIN

2PC’S x 3.860 MT; BOWER ANCHOR STOCKLESS JIS TYPE

1st SHACKLE x 13.75 M + 9 SHACKLES x 27.50 M; DIA = 54 MM

INSPECTION PLACE

CHINA

DELIVERY PLACE

CHINA

PRICE

USD 7.5 MILLION

REMARKS

REEFER PLUGS: 21

CONTAINER CAPACITY: 21 FEU ON WEATHER DECK & HATCHCOVERS

DIFFERENT TEMPS: 8/2 PER HOLD
