| VESSEL NAME | REF662 |
| TYPE | REEFER CARRIER |
| DEEP FREEZING OR NOT | NO |
| FLAG | ST.VINCENT AND THE GRENADINES |
| PORT OF REGISTRY | KINGSTOWN |
| BUILT YEAR | 1988 |
| BUILT PLACE | HAYASHIKANE, JAPAN |
| CLASSIFICATION | RMRS |
| CLASS NOTATION | KM REF ICE 2 |
| LOA (M) | 145.50 |
| LBP (M) | 136.87 |
| BEAM (M) | 22.60 |
| DEPTH (M) | 13.00 |
| SUMMER DRAFT (M) | 9.20 |
| GT (MT) | 10298.00 |
| PANAMA GT (MT) | 11318.14 |
| SUEZ GT (MT) | 11155.00 |
| NT (MT) | 4653.00 |
| PANAMA NT (MT) | 8705.28 |
| SUEZ NT (MT) | 8066.30 |
| SUMMER DWT (MT) | 11055.00 |
| LDT (MT) | 5973.00 |
| DISPLACEMENT (MT) | 17029.00 |
| GEAR(S) | ELECTRIC CRANES: 2 x 30MT; 2 x 10MT |
| M/E(S) | B&W 6L60MCE, 10670BHP, 111RPM TURBO CHARGER: MITSUI-MAN NA57/N7 |
| M/E POWER (KW) | 7850 |
| A/E(S) | 4 x DAIHATSU DIESEL 6DL-24, 1100BHP/809KW, 720RPM 1 x EMERGENCY ENGINE: MITSUI-DEUTZ BF6L 913C, 80KW 1800RPM |
| GENERATOR(S) | 4 x FUJI A.C. 450V 60HZ 750KW 720RPM 1 x EMERGENCY GENERATOR: FUJI A.C.450V 60HZ 80KW 1800RPM |
| SPEED/CONSUMPTIONS | 19KTS; 20KTS AT 32MT/DAY |
| FUEL TYPE | IFO |
| NUMBER OF CARGO HOLDS | 4 |
| HATCH NUMBER | 4 |
| HATCH SIZE (M) | 9.0 x 7.0 |
| COMPARTMENT(S) | 16 |
| DECK HEIGHT (M) | 2.2 |
| CARGO CAPACITY (CBFT) | 543430 |
| CARGO CAPACITY (CBM) | 15395 |
| FLOOR SPACE CAPACITY (SQM) | 5743 |
| GRATING/DECK STRENGTH | SUITABLE FOR PNEUMATIC FORKLIFTS WITH ALL-UP WEIGHT OF 6.5MT |
| TEMPERATURE ZONE(S) | 8, 1AB/CD, 2AB/CD, 3AB/CD, 4AB/CD |
| TEMPERATURE (℃) | -25/+15 |
| VENT (TIMES/HOUR) | 90 |
| AIR CHANGE (TIMES/HOUR) | 4 |
| PALLET(S) | 4300 |
| CONTAINER CAPACITY | 33 FEU |
| REEFER PLUG(S) | 66 |
| INSURANCE | P&I – INGOSSTRAKH, MOSCOW H&M - ROSGOSSTRAKH, MOSCOW, AS LEADER |
| DELIVERY | APRIL, PERU |
| PRICE | USD 2.6 MILLION |
