MTU Germany 2080kW Diesel Generator Never used

This Diesel Emergency Power Generator was for

off-shore oil rig originally.

Type: Skid type

Make: MTU (Germany)

Manufacturing year: 2014

Model: 164000 P63

Quantity: 1 set

Site data

Ambient temp: Min,-7 , Max. 25

Humidity (% R.H):  Min. 28, Max. 100

Engine data

Continuous rated capacity: 2080 kW

Rated RPM: 1500

Cycles: 4

Rated BMEP: 21.8 barg

Minimum RPM: 1500

Overspeed trip: 1725 rpm

Turbocharger : 0-50000 rpm

No of cylinders: 16

Bore: 170mm

Stroke: 210mm

Configuration: V type

Fuel rate (kg/kWh) at rated load: 0.197

Fuel rate (kg/kWh) at 75% load: 0.199

Fuel rate (kg/kWh) at 50% load: 0.205

Cylinder liners type: Wet

No. of rings & size of compression: 3&18.7 bar

Exhaust valve: No. 2

Inlet valve: No. 2

Exhaust manifold: wet type, Cooled type

Vibration dampers: There is.

Torsional calculation : There is

Generator data

Capacity: 1950 kWe

Make: MTU

RPM: 1500

Volt: 690 V

Phase: 3 phase

Frequency: 50HZ

Starting system

Primary: electric starting system

Secondary: Hydraulic starting system

Electric equipment make:

Bosch Slidinggear starter motor

Battery capacity: Amph apprpx. 250 (2 x100%)

Hydraulic equipment make: Huegli

Fuel system

Diesel type: Diesel oil

Tank: Sized for 18 hours at full load

Water separator: There is

Oil filter: There is

Governor

Type: Constant speed

Make: MTU

Speed range: 1400~1600rpm

Tachometer: electrical type

Auxiliary equipment

Make: MTU

Lube oil pump: integral type,

Drive:engine drive

Capa.: 42 m3/h

Jacket water pump: There is,

Drive: engine drive

Capa.: 80 m3/h

Atmospheric Emissions

Content O2 in combustion 8.4%

NOx: 7g/ kWh

Unburnt Hydrocarbons VOC: 0.09 g/ kWh

CO2: 612 g/ kWh

CO: 1 g/ kWh

Floor Space

Approx floor space: 3120 mm (L) x 1580 mm (W) x 2060 mm (H)
