144' Five Section full power partially synchronized telescoping boom of round box construction with auxiliary lifting sheave,
33' - 58' Two stage bi-fold lattice type with 3.5, 25 or 45 degree offset (Tilt Type) Jib - Assistant cylinders for mounting and stowing, controlled at right side of superstructure,
Main and Auxiliary Winches with 3/4" wire rope,
Two Speed,
Drum Rotation Indicator- (audible and visible type) main and auxiliary hoist, Tadano electronic Load Moment Indicator system (AML-C) including:
Control lever lockout function,
Boom position indicator,
Outrigger state indicator,
Boom angle / boom length / jib offset angle / jib length / load radius / rated lifting capacities / actual loads read out
Ratio of actual load moment to rated load moment indication,
Anti-Two Block (overwind cutout),
Hook Ball and Block,
Tadano twin slewing system and 360 degree positive slewing lock,
Outrigger controls and sight level in the operator's cab,
Self-removable counterweight,
Tadano 4 X 4 X 4 drive and steer Carrier,
Mitsubishi Tier 3 Diesel Engine,
Electronically controlled full automatic transmission. Torque converter driving full powershift with driving axle selector. 6 forward and 2 reverse speeds, constant mesh. 3 speeds - high range - 2 wheel drive; 4 wheel drive - 3 speeds - low range - 4 wheel drive,
Air Conditioner and Heater,
Tilt-telescoping steering wheel
Front and Rear Tires: 29.5 x 25,
Four hydraulic, beam and jack outriggers. Vertical jack cylinders equipped with integral holding valve. Each outrigger beam and jack is controlled independently from cab. Beams extend to 23' 11-3/8" center-line and retract to within 10' 10-1/2" overall width with floats,
