3-in-1 laser welder with cleaning and cutting function

The ZJ-WD laser welder is a 3-in-1 device that combines precision welding with cutting and cleaning capabilities.

• Fast and easy welding of even thin materials -Best laser welders are all about the easy creation of professional welds, the low cost of operating the device, and the ability to join together materials with different properties, such as stainless steel and aluminum.

• Laser cleaning - by making maximum use of the laser generator's capabilities, you can switch the device to cleaning mode and effectively remove contaminants from the material before welding or from a freshly made weld. Laser ablation is the most environmentally friendly solution that quickly and without the use of chemicals removes dirt such as rust, paint, oil and others.

• Cutting metal  - properly adjusted mode changes the parameters of the beam and allows you to cut material up to 4 mm thick.



Laser welding - joining materials has never been so easy!

The device is designed to make its operation as simple as possible for users, so creating welds does not require special operator training. The ability to weld with a handy head that operates in 360 degrees is undoubtedly one of the biggest advantages of this model. The ZJ-WD welder can perfectly cope with the production of parts made of thin metal sheets. In addition, laser technology allows you to join different materials together, which is virtually impossible with traditional welding methods. An automatic wire feeder is also an integral part of the machine . This supports the operator's work - it helps guide the movement that creates the weld. The feeder has adjustable parameters, such as the delay time (delay), for example. It also has many other functions, including: Rollback (reversing the wire and winding it on the spool), or Push-Pull (feeding the wire properly and pushing back the welder's hand). Also included is a set of nozzles that can be quickly replaced and thus give a different shape to the weld and reach hard-to-reach areas such as curves or angles. The device does not require the use of electrodes, and thanks to the small laser beam, it is possible to weld with minimal spacing. Controlling the laser power, beam width, frequency and other parameters, the workpiece is melted, creating a perfect quality weld, as confirmed by the tests carried out and the Welding Quality Control Institute certificate.


Many functions in one device!

The three functions in one ZJ-WD not only save time, but above all are attractively priced, especially considering the large production capacity and wide range of applications of this model. It is a comprehensive solution that will streamline the work of any production facility, as it combines the functions of a welding machine, cleaning laser and fiber optic cutter.



Advantages of Best Laser ZJ-WD laser welding machine

High quality, repeatability and strength of welds that do not require further processing

Easier to create aesthetically pleasing, long joints in one motion

Low operating costs and maintenance of the device

Intuitive operation and high process cleanliness

High welding speed While maintaining quality, The ability to Work in longer intervals, Relatively Low power consumption

Handy head Allows 360-degree maneuverability

Ability to clean and cut workpiece materials



Advantages of Best Laser ZJ-WD laser welding machine

Compared with traditional welding techniques in production, laser welding is more environmentally friendly and easier to operate. Laser technology is more popular, bigger in your budget and is the most important and safer machine. With a variety of welding methods: spot welding, butt welding, lap welding, sealing welding, etc. can be realized. High aspect ratio, small weld width, small heat-affected zone, small deformation, fast welding speed, smooth and beautiful weld seam, no need or simple treatment after welding. High quality welding seam, no porosity, can be precisely controlled, small focal point, high positioning accuracy, easy to automate.

Stable operation, beautiful weld seam, fast welding speed, no consumables. It perfectly renews traditional welding strategies: arc welding and electric welding of the following materials: stainless steel, iron, galvanized or different metallic materials.

Different welding methods can be easily realized by changing different welding heads. The welding speed is faster, 2-10 times faster than traditional welding. Each machine saves labor costs of at least 2 operators per year, consumes less, has a longer life, and welding is safer and more environmentally friendly.

Easy operation: no experienced welding operators are required, novices can operate it.

Little or no post-processing: No polishing machine or sander is required, which greatly saves labor and time costs.

Laser welding is widely used in complex and abnormal welding processes: kitchen cabinets, stair lifts, shelves, ovens, stainless steel door and window guardrails, power distribution, various high-reflective metals and other industries


Component features.

Safety protection fuselage

The overall design pays more attention to the safety of operators, and the product design complies with EU and international safety standards. Multiple safety protection functions, higher safety protection

Handheld Laser Welding Head

Welding, cutting, cleaning, and post-welding cleaning can be realized by replacing the laser head parts, one machine with multiple functions. Equipped with safety sensing function, laser light will be emitted after touching the metal, and the light will be automatically locked when it is removed. Spiral shaking function, the weld width can be adjusted, and the welding ability is significantly improved. A variety of tip components are included in the standard kit to complete cutting, welding and weld cleaning. Assembly for remote cleaning is optional.

Welding Control System

High-performance, intuitive and easy-to-use operating system. Controls are placed on the color touch display, allowing you to set all necessary parameters according to user needs. The system can save a variety of craft modes, which can be quickly set up before work. The system supports multiple language versions.

Select the power and type of laser generator

The power of the laser generator affects the speed of melting and the speed of weld formation. By generating more energy faster, the higher-powered source makes it much easier to work with difficult metals. The higher power allows welding thicker materials by creating more extensive and stronger welds

Automatic wire feeder (optional)

The automatic wire feeder is designed to combine simple operation and control of the machine with excellent wire feeding performance. Effectively fills the weld to make the weld stronger.

To see the contact details please Login or Register
Contact Name:
Company Name:
Mobile Phone:
Phone:
Fax:
Country:
E-Mail:
Web:

Comments      Add New Message

Leave a reply

Replace the security code

What is 3 in 1 Laser Welding Machine ?

A 3 in 1 laser welding machine is a specialized piece of equipment that integrates three different laser welding technologies into a single machine.

The three technologies typically included in a 3 in 1 laser welding machine are:

  1. Fiber laser welding: This technology uses a high-powered fiber laser to create a focused beam of light that melts and fuses metals together. It is a fast and precise welding technique that is ideal for welding small to medium-sized parts.

  2. YAG laser welding: This technology uses a pulsed YAG laser to weld metals. It is particularly useful for welding thin metals and for creating precise welds in areas that are hard to reach.

  3. CO2 laser welding: This technology uses a CO2 laser to weld metals. It is a versatile welding technique that is well-suited for welding thicker metals and for performing continuous welds.

By combining these three technologies, a 3 in 1 laser welding machine can offer a wide range of welding capabilities, allowing manufacturers to perform a variety of welding tasks with a single machine. This can help increase efficiency, reduce costs, and improve overall productivity in manufacturing operations.
