PRINCIPAL DATA
Type 4cycle main propulsion diesel engine.
No. of Cylinder 6
Cylinder Bore 170mm
Stroke 230mm
Mean Effective Pressure 1.06 - 2.21MPa
Mean Piston Speed 10.35/11.12 m/s
Rated Power
| Engine Model | 6EY22AW | |||||
|---|---|---|---|---|---|---|
| Continuous Rated Power [kW(PS)] | 736 (1000) |
885 (1203) |
1030 (1400) |
1180 (1604) |
1330 (1808) |
1370 (1863) |
| Rated Engine Speed [min-1] | 800 | 850/900 | 900 | |||
| Engine Dry Weight [kg] | 10000 | |||||
Standard Marine Gear
| Propeller Type | for F.P.P. | ||
|---|---|---|---|
| Marine Gear Model | Offset | YX-1000 | YXH-2000 |
| Co-Axial | YX-1000C | YXH-2000C | |
| Reduction Gear Ratio [Ahead] | Offset | 2.03, 2.36, 2.78, 3.32 | 2.23, 2.58, 2.79, 3.03 |
| Co-Axial | 2.03, 2.36, 2.78, 3.32 | 2.23, 2.58, 2.79, 3.03 | |
| Marine Gear Dry Weight [kg] | Offset | 2400 | 4750 |
| Co-Axial | 2565 | 5050 | |
[mm] / [kg]
| Engine Model | Marine Gear | A | A1 | A2 | A3 | B | C | D | E | F | G | Total Dry Weight with Marine Gear |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6EY22AW 736kW |
YX-1000 | 4574 | 3647 | 2965 | 1488 | 1548 | 2326 | 666 | 885 | 435 | 1922 | 12505 |
| YX-1000C | 4687 | 3647 | 2965 | 1601 | 1548 | 2326 | 666 | 450 | - | 1922 | 12670 | |
| 6EY22AW 885kW |
YX-1000 | 4574 | 3647 | 2965 | 1488 | 1618 | 2416 | 666 | 885 | 435 | 1922 | 12505 |
| YX-1000C | 4687 | 3647 | 2965 | 1601 | 1618 | 2416 | 666 | 450 | - | 1922 | 12670 | |
| 6EY22AW 1030kW |
YX-1000 | 4603 | 3647 | 2965 | 1517 | 1618 | 2416 | 666 | 885 | 435 | 1922 | 12556 |
| YX-1000C | 4636 | 3647 | 2965 | 1550 | 1618 | 2416 | 666 | 450 | - | 1922 | 12721 | |
| 6EY22AW 1180kW 1330kW 1370kW |
YXH-2000 | 4810 | 3647 | 2965 | 1807 | 1618 | 2416 | 666 | 1145 | 590 | 1922 | 14861 |
| YXH-2000C | 4960 | 3647 | 2965 | 1957 | 1618 | 2416 | 666 | 555 | - | 1922 | 15161 |
|
|
|
|
|
|
